Carrier 42VL Fan Coil Unit: Models, Specifications, and Supply in Pakistan

The Carrier 42VL Fan Coil Unit is a water-based terminal unit designed for 2-pipe HVAC systems. The series includes seven models, from the 42VL002 to the 42VL012. Airflow ranges from 340 to 2,040 m³/h, cooling capacity from 2,200 W to 11,200 W, and heating capacity from 3,520 W to 18,000 W.

Every model shares the same core design: quiet motors and fans, 3-speed fan control, a copper and aluminum coil, and a heavy-gauge galvanized steel casing lined with closed-cell, fire-retardant foam. This makes the range a practical choice for HVAC contractors, MEP consultants, builders, and facility managers working on chilled water projects across Pakistan.

Quick answer: The Carrier 42VL series is a range of seven chilled water fan coils for 2-pipe systems. Models deliver 340 to 2,040 m³/h of airflow, 2.2 to 11.2 kW of cooling, and 3.52 to 18 kW of heating. They run between 36 and 49 dB(A), draw 36 to 183 W, weigh 19 to 48 kg, and support valve packages and optional thermostats.

What this guide covers:

• How a water-based fan coil works in a 2-pipe system
• Full model-by-model specifications in one table
• Key features, benefits, and a model selection guide
• Applications in Pakistani homes, offices, hotels, hospitals, and institutions
• An installation and maintenance checklist
• Answers to common buyer questions

---



What Is a Fan Coil Unit?

A Fan Coil Unit is a room-level HVAC device that cools or heats air using water from a central plant. A fan draws room air across a water-filled coil. In summer, chilled water from a chiller removes heat and moisture. In winter, hot water from a boiler or heat pump warms the air.

Unlike a split air conditioner, a Fan Coil Unit has no compressor inside the room. The heavy work happens at the central plant, so each terminal runs quietly and draws very little electricity. This is why chilled water systems are common in hotels, hospitals, malls, and multi-story office buildings.

How a 2-Pipe System Works

A 2-pipe system uses one supply pipe and one return pipe for each fan coil. The building switches between chilled water and hot water depending on the season.

1. Summer: The central chiller sends cold water through the supply pipe to every fan coil.
2. Winter: The plant changes over and sends hot water through the same pipes.
3. Return: Water flows back to the plant through the return pipe.
4. Control: A thermostat and valve package at each unit regulate comfort room by room.

This setup is simple, cost-effective, and easy to integrate into existing HVAC systems. It suits Pakistan well, where cooling dominates most of the year and northern cities such as Islamabad and Rawalpindi also need winter heating.

---



Carrier 42VL Fan Coil Unit Technical Specifications

The table below lists every model in the 42VL series with its full performance data. The approximate CFM and TR columns are conversions to help you compare against local project drawings and quotations.

Model	Airflow (m³/h)	Approx. CFM	Cooling Capacity (W)	Approx. Cooling (TR)	Heating Capacity (W)	Power Input (W)	Sound Level [dB(A)]	Water Flow (l/min)	Weight (kg)
42VL002	340	200	2,200	0.63	3,520	36	36	6.3	19.0
42VL003	510	300	2,900	0.82	4,640	50	38	8.4	21.0
42VL004	680	400	3,700	1.05	5,920	60	41	10.6	23.5
42VL006	1,020	600	5,400	1.54	8,370	93	45	15.5	28.0
42VL008	1,360	800	7,400	2.10	11,470	130	46	21.3	38.0
42VL010	1,700	1,000	10,000	2.84	15,500	147	46	28.7	48.0
42VL012	2,040	1,200	11,200	3.18	18,000	183	49	32.1	48.0

Conversions: 1 m³/h ≈ 0.589 CFM; 1 TR ≈ 3,517 W. Confirm final ratings against the manufacturer’s data at your design water temperatures.

Reading the Model Numbers

The model number gives a quick clue to size. The digits roughly match nominal airflow in hundreds of CFM. For example, the 42VL004 moves about 400 CFM and the 42VL010 moves about 1,000 CFM. This makes it easier to match units to schedules on mechanical drawings.

What the Numbers Mean in Practice

• Cooling from 0.63 to 3.18 TR: The range covers everything from a small bedroom or hotel room to a large open-plan office zone.
• Power input from 36 to 183 W: Each unit’s own electricity draw is very low. Most energy use sits at the central chiller.
• Sound from 36 to 49 dB(A): Smaller models are quiet enough for bedrooms and patient rooms. Larger models suit offices and lobbies.
• Water flow from 6.3 to 32.1 l/min: These figures help MEP engineers size pipes, pumps, and balancing valves.
• Weight from 19 to 48 kg: Installers can plan supports and handling for each size.

---



Key Features of the 42VL FCU

Every 42VL FCU is built around three goals: steady comfort, low noise, and easy servicing. Here’s how each feature supports those goals.

Wide Airflow Range

Seven models from 340 to 2,040 m³/h let you match each room’s load closely. Right-sized units cycle less, control humidity better, and keep running costs in check.

2-Pipe System Compatibility

The series is designed for 2-pipe system combinations. That allows straightforward integration into new buildings and existing chilled water networks.

3-Speed Fan Control

A 3-speed fan lets occupants choose low, medium, or high airflow. Low speed keeps rooms quiet at night. High speed pulls down heat quickly after a hot afternoon.

Quiet Motors and Fans

Low-noise motors and fans keep sound levels between 36 and 49 dB(A). This matters in spaces where people sleep, study, heal, or hold meetings.

High-Efficiency Coil

The coil uses copper tubes mechanically bonded into slit aluminum fin collars. Copper moves heat quickly, and the slit fin design increases contact between air and fin surface. The result is efficient heat transfer for both cooling and heating.

Durable Construction

The casing is made from heavy-gauge galvanized steel. It is insulated with closed-cell, fire-retardant foam that resists moisture, limits corrosion, and helps extend unit life.

Easy Maintenance

The motor and fan assembly can be removed easily. Technicians can service or replace parts without disturbing the whole unit, which saves time on site.

Flexible Controls and Options

• Valve packages: Compatible 2-way or 3-way valves support system control and zoning.
• Thermostats: Optional controllers include the TMS710/720 and TMS8103.
• Coil configurations: Different coil options suit specific application needs.

---



Benefits at a Glance

Benefit	Supporting Feature	Why It Matters for Your Project
Accurate sizing	Seven models, 340–2,040 m³/h	Matches each room’s load without oversizing
Low running costs	36–183 W power input	Keeps terminal electricity use minimal
Quiet comfort	Quiet motors and fans, 36–49 dB(A)	Suits bedrooms, hotel rooms, wards, and offices
Year-round use	2-pipe design with heating capacity	Cools in summer and heats in winter
Occupant control	3-speed fan, optional thermostats	Lets users adjust comfort room by room
Zoning flexibility	2-way and 3-way valve packages	Supports balanced, efficient water distribution
Long service life	Galvanized steel, fire-retardant foam	Resists corrosion and supports safety goals
Faster servicing	Removable motor/fan assembly	Reduces downtime for facility teams

---



Model Selection Guide

Choosing the right model starts with an accurate heat load calculation. The table below gives typical uses for each size as a starting point.

How to Size a Carrier 42VL Fan Coil Unit for Your Project

Model	Approx. Cooling	Typical Application
42VL002	0.63 TR	Small bedrooms, hotel rooms, private cabins
42VL003	0.82 TR	Bedrooms, small offices, clinic rooms
42VL004	1.05 TR	Master bedrooms, consultation rooms, classrooms
42VL006	1.54 TR	Living rooms, meeting rooms, patient wards
42VL008	2.10 TR	Open offices, retail shops, lounges
42VL010	2.84 TR	Large offices, showrooms, restaurants
42VL012	3.18 TR	Lobbies, halls, large retail and dining areas

Selection tips:

1. Calculate the real heat load. Include glazing, sun exposure, occupancy, lighting, and equipment.
2. Check design water temperatures, since capacity changes with supply and return conditions.
3. Compare sound levels with the room’s use, especially for bedrooms and healthcare spaces.
4. Confirm water flow so pipes and pumps are sized correctly.
5. Choose a valve package and thermostat that suit your control strategy.

---



Applications Across Pakistan

Pakistan’s climate puts heavy demand on cooling systems. Karachi deals with high humidity. Lahore, Multan, and Faisalabad face intense summer heat. Islamabad and Rawalpindi also need winter heating. The 42VL range covers all of these needs with one consistent product line.

• Residential: Villas, farmhouses, apartments, and high-rise residential towers
• Commercial offices: Corporate offices, IT companies, and co-working spaces
• Hospitality: Hotels, resorts, guest rooms, restaurants, and serviced apartments
• Healthcare: Hospitals, clinics, patient rooms, and diagnostic labs
• Institutional: Schools, colleges, universities, libraries, and public buildings
• Retail: Shops, showrooms, and units inside malls

Why Contractors and Consultants Choose the Carrier 42VL FCU

The Carrier 42VL FCU gives each project team something useful:

• HVAC contractors: Removable fan assemblies and manageable unit weights make installation and servicing easier.
• MEP consultants: Clear airflow, capacity, sound, and water flow data support accurate design and specification.
• Builders and developers: A trusted international brand adds value to residential and commercial units.
• Facility managers: Low power draw, quiet operation, and easy maintenance help control operating budgets.

---



Installation and Maintenance Checklist

Follow these steps to get reliable performance from every unit:

1. Select each model based on a room-by-room heat load calculation.
2. Install on structure that safely supports the unit weight, from 19 to 48 kg.
3. Connect supply and return pipes with proper insulation to prevent condensation.
4. Fit the chosen 2-way or 3-way valve package and test it before handover.
5. Balance water flow to the rated figure for each model.
6. Set up thermostats and test all three fan speeds.
7. Clean or replace filters regularly, especially in dusty cities.
8. Inspect the coil, drain tray, and motor/fan assembly during scheduled servicing.

---



Buy Carrier FCU Models in Pakistan from Workman Services

Workman Services has delivered HVAC&R and fire fighting solutions since 2006. Our team of designers, sales engineers, and certified technicians handles system design, supply, installation, testing, commissioning, and maintenance for residential, commercial, industrial, and healthcare projects.

When you source a Carrier FCU through us, you get more than equipment. We help match each Carrier 42VL FCU to your heat load, confirm valve and thermostat options, and coordinate delivery to your site. Our experience covers chiller systems, AHUs, VRF systems, ducting, and fan coil supply for malls, retail outlets, offices, and residences.

What you can expect:

• Project quotations for single units or bulk orders
• Technical guidance on model selection and system design
• Product data for submittals and consultant approvals
• Installation, commissioning, and after-sales support

Our branches: Lahore, Rawalpindi, and Faisalabad, with a presence in the UAE.

Call or WhatsApp +92 306 4410583 or email info@workmanservices.com.pk to request pricing and availability.

---



Frequently Asked Questions

What is the airflow range of the Carrier 42VL series?

The series covers 340 to 2,040 m³/h, or about 200 to 1,200 CFM. The smallest model is the 42VL002 and the largest is the 42VL012.

Which 42VL FCU model is best for a hotel room?

The 42VL002 or 42VL003 usually suits a standard hotel room. They deliver 2,200 W and 2,900 W of cooling at just 36 and 38 dB(A). Always confirm with a heat load calculation.

Is the Carrier 42VL FCU suitable for heating as well as cooling?

Yes. In a 2-pipe system, it uses chilled water in summer and hot water in winter. Heating capacity ranges from 3,520 W to 18,000 W depending on the model.

Does a Fan Coil Unit need a chiller?

Yes, for cooling. It needs a chiller or central plant to supply chilled water. For heating, it needs a hot water source such as a boiler or heat pump.

How much electricity do 42VL units use?

Power input ranges from 36 W for the 42VL002 to 183 W for the 42VL012. Most cooling energy comes from the central chiller, not the terminal unit.

How quiet are the 42VL models?

Sound levels range from 36 dB(A) on the smallest model to 49 dB(A) on the largest. This suits bedrooms, patient rooms, classrooms, and offices.

Which thermostats and valves are available?

Optional thermostats include the TMS710/720 and TMS8103. You can also choose 2-way or 3-way valve packages and different coil configurations.

Can I order a Carrier FCU with a valve package for zoning?

Yes. The range is compatible with 2-way and 3-way valve packages, which support individual room control and zoned chilled water distribution.

Where can I buy Carrier 42VL models in Pakistan?

Workman Services supplies and installs them across Pakistan, with branches in Lahore, Rawalpindi, and Faisalabad. Contact us at +92 306 4410583 for a project quotation.

---



Final Thoughts

The Carrier 42VL Fan Coil Unit range brings flexible sizing, quiet operation, and year-round comfort together in one dependable product line. With seven models, 2-pipe compatibility, 3-speed fans, durable galvanized construction, and easy-to-service components, it fits projects from single villas to large hotels and hospitals.

Review your heat loads, confirm your water design conditions, and speak with the Workman Services team for model selection, pricing, and complete installation support.
