Description

Performance Features

• Full-load EER values up to 10.9 and IPLV values up to 19.0 (units with Greenspeed intelligence)
• ASHRAE 90.1-2019/2022 complaint / AHRI certified
• High efficiency variable condenser fans (Greenspeed intelligence) / Low sound levels
• Operation from -20 °F to 125 °F ambient conditions
• Standard uncoated or optional e-coated Novation® microchannel heat exchanger (MCHX) or Aluminum-Copper condenser coils
• Hydronic pump package (with or without VFD) on sizes 065-252
• Desuperheater
• Robust Brazed-Plate or Shell-and-Tube evaporator
• Compact unit design
• PIC6 graphic display with BACnet™ IP

Additional Important Options

• Energy Management Module minimizes chiller energy consumption
• Non-fused disconnect switch
• Minimum load control
• PIC6 7-inch display pairs with Carrier Comfort Network©
• Al/Cu e-coated condenser coil
• Pairable with Free-Cooling (09FC)
• Low GWP refrigerant R-32
• Security grilles and Hail guards/Privacy screen choices
• Greenspeed intelligence (low ambient operation)
• Coil corrosion coatings available on all coil types
• High short circuit current rating

Reliability Features

• ASME constructed DX evaporators
• ETL (and ETL Canada) listed
• Galvanized steel frame
• EXV (Electronic expansion valve)

Maintenance Features

• Diagnostic functions available through PIC6: Touch Screen Control Panels
• Permanently lubricated fan motor bearings
• Compressor suction service valves (option)
• Microchannel condenser coils with inherent corrosion resistance and offering simplified cleaning
• Unit-mounted, non-fused disconnect (option)
• Remote connectivity for easier machine diagnostics

Installation Features

• Factory charged with low GWP HFC refrigerant R-32 (or R-410A)
• Integrated hydronic pump package (with or without VFD) on sizes 065-152 (factory-installed option, but N/A with desuperheater option)
• Single or dual-point electrical connections available
• Integral control transformer
• Galvanized steel frame

Factory-Installed Options

• High efficiency variable condenser fans (Greenspeed Intelligence)
• Hydronic pump package with or without VFD (sizes 065-152)
• Desuperheater
• Condenser coil options:
  • Microchannel: Non-coated, E-coated
  • Aluminum fins/Copper tube: Non-coated, E-coated
• BACnet™ IP or MS/TP
• Remote Connectivity
• Energy Management Module
• LON or Modbus translator control
• 7-inch Control Panel Display
• Compressor sound reduction blankets
• Compressor suction service valve
• Minimum Load Control
• Chicago Relief Valve
• Condenser coil trim panels
• Full Hail Guard
• Security grilles
• Security grilles (sides) and Hail Guards (Ends)
• Single or dual-point electrical connection
• Convenience outlet
• Freeze protection (evaporator heaters)
• Suction line insulation
• High short circuit current rating (High SCCR)
• Non-fused disconnect
• Direct Expansion Shell-and-Tube evaporator
• CRN evaporator

Field-Installed Accessories

• Compressor sound reduction blankets
• Energy Management Module
• LON (local operating network) translator control
• Condenser coil trim panels
• Wind Baffles
• Fan VFD Display
• Dual-chiller accessory kit

30RC Weights & Dimensions

Size	Weight (lb)	Weight (kg)	Length (in)	Length (mm)	Width (in)	Width (mm)	Height (in)	Height (mm)
067	3408	1546	105	2678	88	2236	99	2517
072	3641	1652
082	3879	1760
092	4639	2105	152	3872
102	4715	2075
112	5090	2230
122	5796	2231	199	5056
132	6211	2730
152	6299	2758
162	7300	3311	247
182	8545	3875	294
202	8686	3939
232	9890	4485	341
252
