Description

Performance Features

• Full-load EER values above 11.0 and IPLV values above 22.0
• Tiered approach providing from the smallest footprint to the best in class efficiency
• ASHRAE 90.1-2022 compliant / AHRI certified
• Operation from -20 F to 125 F ambient conditions
• High-efficiency variable speed screw compressors
• Standard uncoated or optional e-coated Novation® micro channel heat exchanger (MCHX) condenser coils (factory-installed option)
• Standard 25kA SCCR rating for all voltages (Except 575V, 10kA)

Additional Important Options

• Al/Cu, Cu/Cu Condenser Coils
• Multiple Sound Configurations
• High SCCR factory installed
• Variable Speed Condenser Fans
• Capacity Recover under 4 mins
• BACnet Translator (factory-installed option) or BACnet and LON translator control (factory-installed option or field-installed accessory)
• Optional Energy Management Module minimizes chiller energy consumption (factory-installed option or field-installed accessory)

Reliability Features

• ASME constructed evaporators / ETL (and ETL Canada) listed
• Heavy-gage galvanized steel frame
• Coil Trim Panels, Security grilles and Full Hail guards/Privacy screen choices (factory-installed option or field-installed accessory)
• Low ambient head pressure control (factory-installed option or field-installed accessory)
• Coil corrosion coatings available on all coil types (factory-installed option)

Maintenance Features

• Over 15 diagnostic functions & trending capability
• Permanently lubricated fan motor bearings
• Compressor suction service valves (factory-installed option)
• Microchannel condenser coils with inherent corrosion resistance and offering simplified cleaning (factory-installed option)
• Unit-mounted, non-fused disconnect (factory-installed option)
• Remote service port for easier machine diagnostics (factory-installed option or field-installed accessory)

Installation Features

• Factory charged with R-513A refrigerant
• GFI (ground fault interrupter) convenience outlet (factory-installed option or field-installed accessory)
• Remote evaporator kit (field-installed accessory)
• Single or dual-point electrical connections available (factory-installed option)
• Control transformer (factory-installed option)
• Structurally robust base

Factory-Installed Options

• Low-Sound
• Sound Optimization
• Condenser Coil Options
• E-Coated Micro Channel
  • Al/Cu Fins
  • Pre-coated Al/Cu Fins
  • Cu/Cu Coils
  • E-Coated Al/Cu Coils
  • E-Coated Cu/Cu Coils
• Isolation Valve
• Suction Line Insulation
• Energy Management Module (EMM) + GFI
• Chilled Water Temperature Reset (via 4-20 mA Signal; EMM Required)
• Demand Limit (via 4-20 mA signal, 2 addition steps; EMM Required)
• Variable Speed Condenser Fans
• BACnet Translator (MS/TP)
• LONworks Translator
• Dual Point Primary Power Entry
• Control Transformer
• Unit Mounted Main Disconnect, Non-fused
• High SCCR
• Condenser Coil Trim Panels
• Security Grilles
• Hail Guards
• Full Hail Guards
• Skid & Bag

Field-Installed Accessory Kits

• Energy Management Module (EMM) & GFI
• Chilled Water Temperature Reset (via 4-20 mA signal; EMM Required)
• Demand Limit
• LONworks Translator
• Dual Chiller Accessory Kit
• Condenser Coil Trim Panels
• Security Grilles
• Full Hail Guard

30XV Weights & Dimensions

Size	Weight (lb)	Weight (kg)	Length (in)	Length (mm)	Width (in)	Width (mm)	Height (in)	Height (mm)
140 S	11110	5039	206	5226	88	2236	99	2513
140 M	11175	5069	206	5226	88	2236	99	2513
140 H	12058	5469	253	6420	88	2236	99	2513
160 S	11175	5069	206	5226	88	2236	99	2513
160 M	12245	5554	253	6420	88	2236	99	2513
160 H	13112	5948	300	7614	88	2236	99	2513
180 S	11362	5154	206	5226	88	2236	99	2513
180 M	12317	5587	253	6420	88	2236	99	2513
180 H	13184	5980	300	7614	88	2236	99	2513
200 S	12317	5587	253	6420	88	2236	99	2513
200 M	13413	6084	300	7614	88	2236	99	2513
200 H	14202	6442	347	8808	88	2236	99	2513
225 S	13185	5981	253	6420	88	2236	99	2513
225 M	14108	6399	300	7614	88	2236	99	2513
225 H	14975	6793	347	8808	88	2236	99	2513
250 S	15415	6992	300	7614	88	2236	99	2513
250 M	16566	7514	347	8808	88	2236	99	2513
250 H	17614	7989	394	10002	88	2236	99	2513
275 S	15864	7196	300	7614	88	2236	99	2513
275 M	16624	7541	347	8808	88	2236	99	2513
275 H	17492	7934	394	10002	88	2236	99	2513
300 S	16624	7541	347	8808	88	2236	99	2513
300 M	17560	7965	394	10002	88	2236	99	2513
300 H	18401	8346	441	11196	88	2236	99	2513
325 S	17560	7965	394	10002	88	2236	99	2513
325 M	18478	8381	441	11196	88	2236	99	2513
325 H	19407	8803	488	12390	88	2236	99	2513
350 S	20672	9377	406	10304	88	2236	99	2513
350 M	22326	10127	453	11498	88	2236	99	2513
350 H	23104	10480	500	12692	88	2236	99	2513
400 S	23760	10777	453	11498	88	2236	99	2513
400 M	24729	11217	500	12692	88	2236	99	2513
400 H	25507	11570	547	13886	88	2236	99	2513
450 S	24729	11217	500	12692	88	2236	99	2513
450 M	26356	11955	547	13886	88	2236	99	2513
450 H	27221	12347	594	15080	88	2236	99	2513
500 S	26356	11955	547	13886	88	2236	99	2513
500 M	27337	12400	594	15080	88	2236	99	2513
