EKCW 1600DA Fan Coil Unit for Concealed Ceiling Cooling and Heating

Looking for a reliable terminal unit that disappears into your ceiling while delivering powerful, whisper-smooth comfort? The EKCW 1600DA Fan Coil Unit is exactly that! This horizontal water recessed ductable model is engineered for concealed installation, giving you clean interiors with serious cooling and heating muscle behind the scenes.

In short: it’s a hydronic fan coil unit that connects to chilled or hot water, pushes conditioned air through ducts, and keeps large commercial and residential spaces perfectly comfortable — all while staying completely out of sight.

If you want strong airflow, flexible three-speed control, and easy maintenance in one tidy package, you’re in the right place.

Why Choose the EKCW 1600DA Fan Coil Unit?

Let’s get straight to what matters. This unit is built for performance and designed for the real world of installers, facility managers, and building owners who want results without fuss.

Here are the standout benefits:

• Powerful cooling output — 13.00 kW nominal cooling capacity keeps busy spaces cool even on the hottest days.
• Strong heating performance — 25.53 kW nominal heating capacity means year-round comfort from a single terminal unit.
• High airflow — up to 1861 CFM moves air efficiently across wide, open areas.
• Flexible control — three-speed fan operation lets you fine-tune comfort and energy use.
• Ducted versatility — 75 Pa external static pressure supports proper duct runs and balanced air distribution.
• Durable heat exchange — a copper tube coil with hydrophilic aluminum fins promotes efficient, long-lasting performance.
• Hidden and tidy — concealed ceiling installation keeps rooms sleek and clutter-free.
• Service-friendly design — built for convenient installation and ongoing maintenance.

Each of these features pairs with a real payoff: lower visual clutter, consistent temperatures, and dependable comfort that keeps occupants happy.

What Is the EKCW 1600DA Horizontal Water Recessed Ductable Terminal Unit?

The EKCW-DA 1600 is a horizontal water recessed ductable fan coil unit designed for concealed ceiling installation. It provides efficient cooling and heating performance with a centrifugal forward-curved fan, three-speed operation, and 75 Pa external static pressure.

In plain terms, this fcu Horizontal Water Recessed Duct able Terminal Unit sits above your ceiling, draws in room air, passes it over a water-fed coil, and then delivers tempered air back through connected ductwork. Because it uses chilled or hot water rather than refrigerant at the unit itself, it slots neatly into chiller-based or hydronic systems.

This makes it an ideal match for buildings already running a central plant. The compact concealed design is perfect for ducted air distribution where appearance, quiet operation, and consistent comfort all matter.

How This Fan and Coil Unit Works

Curious about the mechanics? Here’s the simple version.

The fan and coil unit pulls warm indoor air across a copper tube coil filled with chilled water during cooling season. Heat transfers into the water, and cool air returns to the room through the ducts. In heating mode, hot water flows through the same coil, warming the air instead.

The centrifugal forward-curved fan, powered by a direct-drive three-speed motor, pushes that air through the ductwork against 75 Pa of external static pressure. That extra pressure capacity is what lets you run longer duct runs and feed multiple diffusers from one unit.

It’s a clean, efficient cycle — and it’s why hydronic systems remain a favorite for larger commercial projects.

Performance Overview of the EKCW 1600DA Fan Coil Unit

When you’re specifying equipment, numbers tell the real story. This fcu fan coil unit delivers balanced performance across cooling, heating, airflow, and sound.

Here’s a quick snapshot of what you can expect:

• Cooling capacity: 13.00 kW for strong, dependable cooling.
• Heating capacity: 25.53 kW for powerful warmth in cooler months.
• Airflow range: 1360 to 1861 CFM across low, medium, and high speeds.
• Sound pressure: 52.9 dB(A), suited to commercial environments.
• Water flow: 1.23 m³/h with a 20 kPa pressure drop for easy system integration.
• Power draw: 665 W rated power on high speed, keeping energy use reasonable.

With three distinct airflow stages — 1861 CFM high, 1749 CFM medium, and 1360 CFM low — you get precise control. Dial it up for peak demand or ease it back for quiet, efficient comfort during off-peak hours.

Where Is the EKCW 1600DA Used?

This Fan Coil Unit is wonderfully versatile. Its concealed, ducted design makes it a smart fit for spaces where both performance and aesthetics count.

Common applications include:

• Offices and corporate workspaces
• Hotels and hospitality venues
• Shopping malls and retail outlets
• Hospitals and healthcare facilities
• Banks and financial branches
• Shops and showrooms
• Residential buildings and apartments
• Commercial buildings of all kinds
• Concealed ceiling ducted applications

Whether you’re outfitting a bustling mall or a quiet office floor, this fcu fan coil unit adapts to the job. The hidden installation keeps interiors looking polished, while the strong airflow handles even demanding, high-traffic rooms.

Who Should Specify This Fan and Coil Unit?

Consultants, mechanical contractors, and facility teams working on chiller or hydronic projects will love this unit. If you need a dependable terminal unit that balances capacity, quiet operation, and a tidy install, this fan and coil unit belongs on your shortlist.

Installation and Maintenance Made Simple

Great equipment should be easy to live with — and this one is designed exactly for that.

Installation Tips

The unit mounts horizontally above the ceiling for a fully concealed finish. Thanks to 75 Pa external static pressure, you can confidently connect it to your duct network and distribute air to multiple outlets.

A few pointers for a smooth install:

• Confirm adequate ceiling clearance for the unit and service access.
• Connect the Rc3/4 condensate drain with proper slope to prevent standing water.
• Match water piping to the 1.23 m³/h flow rate and allow for the 20 kPa pressure drop.
• Wire to a standard 220–240V / 1Ph / 50Hz supply.
• Balance duct runs to make the most of the available static pressure.

Maintenance Guidance

Routine care keeps this fcu Horizontal Water Recessed Duct able Terminal Unit running at its best for years. The hydrophilic aluminum fins resist buildup and support easy cleaning, while the direct-drive motor keeps moving parts to a minimum.

Simple habits go a long way:

• Inspect and clean the coil periodically to maintain airflow and heat transfer.
• Check the condensate drain to keep it clear and free-flowing.
• Confirm all three fan speeds operate correctly during service visits.
• Review water connections for any signs of leaks or corrosion.

Because the design prioritizes convenient installation and maintenance, your service team spends less time wrestling with access and more time keeping comfort dialed in.

Technical Specifications

Here’s the complete technical breakdown for the EKCW 1600DA Fan Coil Unit:

Frequently Asked Questions

What is the EKCW 1600DA Fan Coil Unit?

It’s a horizontal water recessed ductable fan coil unit built for concealed ceiling installation. It uses chilled or hot water to deliver 13.00 kW cooling and 25.53 kW heating through connected ductwork.

How much air does this Fan Coil Unit move?

The unit offers three airflow stages: 1861 CFM on high, 1749 CFM on medium, and 1360 CFM on low. This range gives you flexible comfort control for different load conditions.

Can this fcu fan coil unit handle ducted installations?

Absolutely! With 75 Pa external static pressure, it’s designed specifically for ducted air distribution. You can run ductwork and feed multiple air outlets from a single unit.

What power supply does the unit require?

It runs on a standard 220–240V / 1Ph / 50Hz supply and draws 665 W at high speed, with a rated current of 3.10 A. That makes electrical integration straightforward on most projects.

How noisy is this fan and coil unit?

Sound pressure is rated at 52.9 dB(A), which suits commercial spaces like offices, malls, hotels, and retail environments where background comfort matters.

Is maintenance difficult on this terminal unit?

Not at all. The copper tube coil with hydrophilic aluminum fins resists buildup, the direct-drive motor reduces wear points, and the concealed layout still allows service access. Regular coil cleaning and drain checks keep it performing beautifully.

Ready to Upgrade Your Comfort System?

The EKCW 1600DA Fan Coil Unit brings together strong capacity, quiet operation, and a clean concealed design — a winning combination for offices, hotels, malls, hospitals, and residential projects alike. It’s the kind of dependable, service-friendly equipment that keeps buildings comfortable and occupants happy, season after season.

Want help specifying the right unit for your next project? Contact our team today for expert advice, pricing, and professional installation support. Let’s create comfort everywhere — together!
